RED MONSTRO
KIT LIST & SPECIFICATIONS

Monstro Kit Daily rates as low as $500 including a helper. Leica R - 3 lens kit $200/day. Call for multi-day and weekly rate discounts. 505.410.2250

Frame Grab Monstro shot with Leica R 50mm F-1.4

MONSTRO KIT

Red Monstro 8K Vista Vision Brain M-00319 – 275 hours
Red Aluminum Vista Vision EF Canon mount
Red 4.7” Touchscreen LCD DSMC2
Red EVF OLED DSMC2 and mount
Red Mini Mag 960 gigs
Black Jet mini mag card reader
RED V-lock I/O Expander DSMC2
IDX VL-2X 2 CH V-lock sequential charger
2 IDX 135wh V-lock batteries
IDX 90wh V-lock battery
Red Carbon Fiber 2 stage matte box 15mm or 19mm
BW Variable ND (will include matte box and filters soon)
ProAim Quick Release Base Plate w/cheese plate - 15mm studio & 19mm
Rods - two 19mm 12"
Miller Compass CX 14 100mm head, Miller Solo 3 stage carbon fiber legs
Red Outrigger Handle w/ record trigger
Wooden Camera Hoodman for 4.7” Touchscreen LCD
Red AC Adapter
Portabrace Camera Case with Wheels

LEICA R LENSES EF MOUNT

19mm- Elmarit F2.8

28mm - Elmarit F.2.8

50mm – Summilux F1.4

Pelican Storm Flight Case

Prices are subject to change at any time. Please call 505.410.2250 to confirm current rental rates. Valid equipment insurance must be available at the time of rental. A signed contract with a prepayment is necessary before any rental will take place. Thank You. Ackerman Digital...

SPECIFICATIONS

The RED MONSTRO 8K VV sensor is a full-frame, 35.4 megapixel CMOS sensor with 17+ stops of dynamic range, offering 8192 x 4320 resolution and accommodating full-frame 35mm lenses for a broad, cinematic look. This sensor is also great for shooting with anamorphic lenses giving you more sensor for better results in low light and clear anamorphic images. The sensor supports the REDCODE RAW codec for high-quality image data and can also record Apple ProRes or Avid DNx files simultaneously for proxy workflows.

Key Characteristics

Resolution: 8K full-frame (8192 x 4320)
Sensor Size: 40.96mm x 21.60mm (full-frame Vistavision)
Megapixels: 35.4 Megapixel
Dynamic Range: 17+ stops, allowing for detail in both shadows and highlights
Maximum Frame Rate: Up to 60 fps at 8K resolution
Codec: Primarily REDCODE RAW, with support for Apple ProRes and Avid DNx formats
Image Processing: Utilizes RED's IPP2 image processing pipeline for advanced image quality and color accuracy
Modularity: A core part of the DSMC2 modular system, allowing for interchangeable lens mounts and other accessories

Benefits

Large Format Coverage:

Its full-frame sensor provides a wider field of view and enhanced depth of field compared to Super 35mm sensors, which is ideal for a cinematic look.
Flexibility with Lenses:

The large sensor area accommodates full-frame 35mm lenses, and Super 35mm lenses can be used with a windowed capture area for high frame rates. Anamorphic lenses have good results in low light and clear anamorphic images.
Versatile Recording Options:

Simultaneously record high-quality REDCODE RAW and proxy files (ProRes or DNx) for faster post-production workflows.
High-Speed Performance:

Windowing the sensor allows for significant frame rate increases, enabling high-quality slow-motion footage.
Advanced Image Quality:

Features improved dynamic range and shadow detail over its predecessor, the DRAGON sensor, and offers enhanced color accuracy.

MAX FRAME RATES60 fps at 8K Full Format (8192 x 4320), 75 fps at 8K 2.4:1 (8192 x 3456)
60 fps at 7K Full Format (7168 x 3780), 75 fps at 7K 2.4:1 (7168 x 3024)
75 fps at 6K Full Format (6144 x 3240), 100 fps at 6K 2.4:1 (6144 x 2592)
96 fps at 5K Full Format (5120 x 2700), 120 fps at 5K 2.4:1 (5120 x 2160)
120 fps at 4K Full Format (4096 x 2160), 150 fps at 4K 2.4:1 (4096 x 1728)
150 fps at 3K Full Format (3072 x 1620), 200 fps at 3K 2.4:1 (3072 x 1296)
240 fps at 2K Full Format (2048 x 1080), 300 fps at 2K 2.4:1 (2048 x 864)
